The Liebherr LR 13000 is the biggest crawler crane in the world, with a lifting capacity of 3,000 tons.

It stands at an impressive 80 meters tall and weighs around 2,600 tons.

This massive machine is powered by a 1,500 kW diesel engine and has a maximum boom length of 100 meters.

Its massive size and lifting capacity make it a game-changer in the construction industry, capable of lifting and moving massive loads with ease.

Biggest Crawler Cranes in the World

The Manitowoc 31000, a crawler crane, stands out with its innovative design and powerful lifting capabilities, reaching up to 700 feet with its Variable Position Counterweight technology. This technology enhances its stability and lifting performance.

The Sarens SGC 250, also known as "Big Carl", is one of the most talked-about cranes in recent years, known for its monumental size and unmatched lifting capacity, with a maximum height of 820 feet. It's frequently seen on large-scale industrial sites, handling tasks that few other cranes can manage.

Credit: youtube.com, Top 5 World’s Largest Crawler Crane in 2023

The Sany SCC45000A, a 4,500-tonne crawler crane, is the largest crawler crane in the world, with a maximum load moment of 98,000 tonne/metres in its twin-boom configuration. It features a 126.5 metre main boom and a 15.5 to 48.5 metre fixed jib.

Here are some of the biggest crawler cranes in the world:

  • Liebherr LR 13000: 246 metres tall and 3,000 tons capacity
  • Terex Demag CC 8800-1 TWIN: 243 metres tall and 2,000 tons capacity
  • Liebherr LR 11000: 222 metres tall and 1,000 tons capacity
  • Terex Demag CC 6800-1: 204 metres tall and 1,250 tons capacity

Manitowoc 31000

The Manitowoc 31000 is a behemoth of a crane, standing at an impressive 700 feet tall. Its innovative Variable Position Counterweight technology enhances its stability and lifting performance.

This crawler crane is designed for heavy industrial projects and can be assembled quickly, reducing downtime and increasing efficiency on job sites. Its maximum lifting capacity is a staggering 2300 tonnes.

The Manitowoc 31000 features a self-supportive counterweight system that minimizes its footprint and need for ground preparation. Its boom is 42 meters long, and it's powered by 2600 HP human engines, creating a total of roughly four 4000 pounds of torque.

Credit: youtube.com, 5 Largest CRAWLER Cranes In The World!

The crane's compact size allows it to be easily moved around the job site. For the operator's comfort and safety, the crane is equipped with an insulated cab featuring large safety glass windows, a tablet-style personal computer, and other essential features.

The Manitowoc 31000 is a game-changer in the construction of power plants and other large-scale industrial projects. Its reliability and adaptability to various environmental conditions make it a valuable asset in the global crane fleet.

Here are some key features of the Manitowoc 31000:

  • Maximum height: 700 feet
  • Maximum lifting capacity: 2300 tonnes
  • Boom length: 42 meters
  • Power: 2600 HP human engines
  • Counterweight system: self-supportive

Sany SCC16000 (1,600)

The Sany SCC16000 is a massive crawler crane that can lift an impressive 1,600 tonnes. It was co-developed by Sany and Guangdong Power Engineering Corporation in 2008.

The R&D for this crane started in October 2008 and orders were secured with customers in China by the end of the same year. This was a significant achievement for Sany.

The Sany SCC16000 complies with the certification requirements of CE, North America, Australia, Russia, and Taiwan. This ensures that the crane meets strict safety and quality standards.

Credit: youtube.com, SANY New 800 Ton Crawler Crane SCC8000A #Sany # crawler crane

This crane is designed to be a direct competitor for the Demag CC 8800-1. It's a testament to Sany's capabilities in the industry.

The Sany SCC16000 made history by being the first crane in its country to lift a 6 MW wind turbine. This demonstrates its impressive lifting capacity and versatility.

Design and Specifications

The Liebherr LR 13000 is the crawler crane with the largest lifting capacity, capable of lifting tremendous weights to great heights. It has a maximum altitude capability of 850 feet.

Its robust design and excellent hauling capabilities make it suitable for tasks such as nuclear power plant building and huge nautical operations. The crane's ability to lift heavy loads is unparalleled in its class.

The LR 13000 has been used on some of the most challenging hoisting projects worldwide, proving its usefulness in extreme conditions. Its design focuses on power, effectiveness, and security, allowing it to accomplish even the toughest tasks effectively.

Liebherr LR 13,000

Credit: youtube.com, The $700 LEGO Technic monster - 42146 Liebherr LR 13000 detailed building review part 1

The Liebherr LR 13000 is a behemoth of a crane, capable of lifting tremendous weights to great heights. It has a maximum altitude capability of 850 feet.

Its robust design and excellent hauling capabilities make it suitable for a variety of tasks, such as nuclear power plant building and huge nautical operations. The crane's ability to lift tremendous weights to great heights is unparalleled in its class.

The Liebherr LR 13000 has been utilized on a number of the most challenging hoisting projects throughout the world, proving its usefulness in circumstances that test the structure of the crane and its operator. Its design focuses not only on power but also on effectiveness and security.

Only a few LR 13000 crawler cranes have been manufactured so far and operated in various regions across the world, including the Netherlands, Germany, Mexico, and Asia.

For your interest: Jib Crane Design

Mammoet PTC 200

The Mammoet PTC 200 is a remarkable crane that offers a unique combination of capabilities. Its Dynamic System on rails allows it to move on project sites with enhanced mobility and flexibility.

Credit: youtube.com, 3 Kg Lego Technic Mammoet PTC-200-DS SSL MOD

This ring crane boasts an impressive lift radius of 800 feet, making it suitable for a wide range of tasks. Its maximum height of 800 feet is equally impressive, allowing it to reach high locations with ease.

The Mammoet PTC 200 is a favorite for large infrastructure projects due to its high capacity and extended reach. Its ability to move on rails makes it uniquely suited for projects that require multiple lifting locations.

The PTC200 DS’s design and capabilities represent a significant advancement in crane technology.

Consider reading: Long Reach Excavator

Design Specifications

The XGC88000 crawler crane is a massive machine that comes in two sections, which is a unique feature compared to most crawler cranes.

The primary section of the crane is where the magic happens, boasting a maximum boom length of 144 meters and a maximum total length of 173 meters.

This section is also where you'll find the crane's maximum height, which is a staggering 108 meters when fully erect. The lifting capacity of this section is impressive, ranging between 3,600 and 4,000 tons, although it can handle a maximum overload of 4,500 tons.

Ship with Crane in Sea on Sunset
Credit: pexels.com, Ship with Crane in Sea on Sunset

The crane's vehicle is powered by three 641 kW (860 hp) U.S. Cummins engine units, which output a total power of 1,923 kW (2,579 hp). Each of these power units can act as a mobile hydraulic power working station or an additional power source during assembly or disassembly.

The crane driver's cabin is a spacious room with an airconditioner, a seat, and a small sofa to accommodate three additional passengers. The cabin is essentially the size of a large office room.

The second section of the crane is a separate tracked compartment that holds the crane's counterweight. This compartment has its own driver's cockpit that can be independently driven and requires a working radius of 29 meters.

The counterweight itself is massive, with a total height of 9.7 meters, a total length of 29 meters, and a weight of 2,900 tons. The maximum weight of the entire vehicle clocks in at nearly 5,400 tons.

Frequently Asked Questions

What is the largest crane in the United States?

The largest crane in the world is the Sarens SGC 250, also known as Big Carl, standing 820 feet tall in Atlanta. This massive crane holds the record for both size and capacity.
